Introduction

Congratulations! You have purchased a Leupold® RX-600 / RX-750 Series digital laser rangefinder that has been designed by Leupold’s engineers and designers to be the best rangefinder on the market and to provide you with years of solid performance in the field.. Following are detailed instructions regarding the proper use and employment of your RX rangefinder.. To ensure top performance for the life of the product, please read these instructions before operating your RX-600 / RX-750..

Your new Leupold RX rangefinder is a revolutionary, range-finding device that incorporates advanced digital electronics with state-of-the-art ballistics algorithms.. RX-600 / RX-750 features include inclinometer, multiple reticle options, and Last Target Mode.. However the truly innovative and unique feature is True Ballistic Range® (TBR), which is available on the RX -750 model.. TBR algorithms were developed by the same engineers who developed Sierra Infinity® Exterior Ballistics Software and who helped develop navigation and guidance systems for ICBMs and other missiles with far more demanding

trajectory requirements than a hunting bullet.. TBR is a marriage of laser ranging, an inclinometer, and an advanced computerized ballistics program.. The result

is distance measurements accurate within a yard, no matter the angle at which the laser is fired.. Bullets and arrows travel in a ballistic arc, yet conventional

rangefinders only provide a linear distance to your target.. TBR delivers the ballistic equivalent range to the target, accounting for the effects of inclines or declines on the path of your bullet or arrow.. Other features that are provided for firearms are outputs that display either MOA adjustments, or inches /centimeters of holdover at that specific distance.. TBR eliminates any potentially significant error, and provides a precise range for your aiming calculations.. TBR is matched to seven rifle ballistics groups and three archery ballistics groups, allowing use with most popular firearms and bows..

HOW THE RX-600 / RX-750 WORKS

The RX-600 and RX-750 are top-quality 6x22mm monoculars that incorporate the additional benefit of a state-of-the-art laser rangefinder capable of measuring the distance of a deer-sized animal from 5 yards to 400 yards (RX-600), 500 yards (RX-750), an inanimate object from 5 yards to 500 yards (RX-600), 600 yards (RX750), and a reflective target from 5 yards to 600 yards (RX-600), 750 yards (RX750).. The rangefinders emit a series of invisible, infrared energy pulses that are reflected off the selected target back to the optical unit.. State-of-the-art circuitry and precision computing circuits are used to calculate the distance by measuring the time it takes for each pulse to travel from the RX-600 / RX-750 to the object and back..

Safety and Operation Precautions

The Leupold RX-600 and RX-750 6x22mm rangefinders employ an eye safe FDA Class 1 and CE Class 3A laser in their operation.. Even so, there are a few precautions that are important to remember:

•Do not depress the POWER button while aiming at a human eye or while looking into the optics from the objective side

•Do not leave the rangefinders within the reach of small children

•Do not take the product apart as it has a self-protection device in the electronic control module and may cause an electric shock

•Do not attempt to use any power source other than a CR2 battery

(or equivalent) — the RX-600 and RX-750 rangefinders are designed to prohibit accessing any other external power supply

•Laser Radiation: FDA Class 1 / CE Class 3A

•Measurement Range: 5 yds – 600 / 750 yds

•Measuring Time: Less than 1 second

• Auto Power Off after 7 seconds

MODE

•Power: CR2 battery or equivalent

•Battery Life: At least 3,000 measurements

• Accuracy: +/- 1 yard/meter

• The RX-600 / 750 are weatherproof

Battery Power Status Indicator

To determine your battery’s power level, look for the following indicators:

FULL – A full battery bar indicates your battery is at or near peak capacity..

HALF – A half-full bar indicates your battery has reached half-capacity..

LOW – If the battery bar is empty, yet there is still data displayed above the bar, the battery is nearing the end of its life and should be replaced..

NO POWER – If the battery bar is empty, and there is no data displayed above the bar, your battery is dead and you must replace it.. The battery status bar will flash and the unit will shut down when no power remains..

MEASURING DISTANCE WITH THE RX-600 / 750

Measurement of distance with the RX-600 / 750 is a very simple operation:

1.View the object of interest through the monocular..

2.Depress the POWER button to power up the unit..

3.Align the reticle over the object being viewed..

4.Depress the POWER button again – this will cause the laser to activate..

5.Read the distance as shown in the image field..

CONTINUOUS MEASUREMENT OF A MOVING TARGET / SCAN MODE:

1.Follow the instructions for “Measuring distance…” as explained previously..

2.Once the target has been measured, continue to hold down the POWER button and follow the object as it moves..

3.The distance will automatically update as long as the POWER button is continuously depressed..

4.This procedure can also be used to obtain the range of multiple animals or objects; simply move the reticle from one target to another while holding down the POWER button..

CLEARING THE LAST DISTANCE OBTAINED:

The last range reading does not need to be cleared before reading another object’s distance.. For that reason, there is no reset button.. Simply aim at the new object using the reticle, depress the POWER button and hold until the new range reading is displayed..

Following is a reference table listing the ranges of the various models under different conditions:

MAXIMUM RANGE

CONDITION	RX-600	RX-750
Reflective Target (yd/m)	600/550	750/685
Trees (yd/m)	500/455	600/550
Deer (yd/m)	400/365	500/455

Surface texture, color, size, and shape of the target all affect reflectivity, which in turn affects the maximum range of the instrument. As a rule of thumb, brightly colored targets are much more reflective than darker targets. Tan game coats are more reflective (and thus provide a more solid reading) than a black roof. A shiny surface is more reflective than a dull surface. Smaller targets are more difficult to range than larger targets. Light conditions, haze, fog, rain, and other environmental conditions can all affect ranging performance. Any factor which degrades air clarity will reduce the maximum effective range. The sun generates infrared energy that can degrade ranging performance in bright conditions or when ranging towards the sun.

Specifications

The RX-600 and RX-750 Series of digital laser rangefinders provides a variety of useful modes to tailor performance to the conditions you experience in the field.. Model features are identified on the following pages..

RX-600	RX-750
Magnification	6×	6×
Inclinometer	No	Yes
TBR (True Ballistic Range)	No	Yes
Last Target Mode	No	Yes
Line of Sight Distance (LOS)	Yes	Yes
Yards / Meters Mode	Yes	Yes
Scan Mode	Yes	Yes
Battery Life	>3,000 Actuations	>3,000 Actuations
Weight	7.0 oz	7.0 oz
Dimension (Inches)	4.2 x 3.0 x 1.6	4.2 x 3.0 x 1.63
Battery Status Indicator	Yes	Yes
Warranty	1 Year	1 Year
Weatherproof	Yes	Yes
Accurate +/- 1 Yard @ <100 yds.	Yes	Yes
